| Part No | Part Name | Material |
|---|---|---|
| 1 | BODY | DUCTILE IRON : BS EN 1563 EN-JS1050 |
| 2 | BONNET | DUCTILE IRON : BS EN 1563 EN-JS1050 |
| 3 | SCREEN | STAINLESS STEEL |
| 4 | GASKET/O-RING | RUBBER : EPDM |
| 5 | STUD | CARBON STEEL : BS 4439 GR.8.8 |
| 6 | NUT | CARBON STEEL : BS 3692 GR.8 |
| 7 | PLUG | DUCTILE IRON : BS EN 1563 EN-JS1030 |
PRESSURE / TEMPERATURE RATING
| Pressure Rating | 25 bar |
| Temperature | -10 to 120 °C |
TEST PRESSURES
| Shell | 37.5 bar |
PLUG DIMENSIONS
| SIZE | THREAD SIZE |
| 65-100 MM | 1/2" BSP |
| 125-250 MM | 3/4” BSP |
| 300 MM | 1” BSP |
SCREEN DIMENSIONS
| SIZE | HOLE SIZE | OPEN RATIO | THICKNESS |
|---|---|---|---|
| 25-80 MM | 1.9 MM | 35% | 26 GAUGE |
| 100-150 MM | 2.5 MM | 40% | 24 GAUGE |
| 200 - 300 mm | 5.0 MM | 48% | 22 GAUGE |
SPECIFICATION
- Strainers fitted with stainless steel perforated stainer element.
- Stainless Screens fitted into Strainers confirm to the high standards of materials.
- Face to Face : BS EN 558:2008.
- End connection : BS EN 1092-1.
- Testing Standard : BS EN 12266-2.
DIMENSIONS & WEIGHTS
| Size | A | B | C | D | E | F | G | H | I | J | Weight(kg) |
| 65 MM | 290 | 65 | 185 | 145 | 16 | 19 | 3 | 118 | 4 | 225 | 14.50 |
| 80 MM | 310 | 80 | 200 | 160 | 16 | 19 | 3 | 132 | 8 | 260 | 18.50 |
| 100 MM | 350 | 100 | 220 | 180 | 16 | 19 | 3 | 156 | 8 | 300 | 24.50 |
| 125 MM | 400 | 125 | 250 | 210 | 16 | 19 | 3 | 184 | 8 | 350 | 37.50 |
| 150 MM | 450 | 150 | 285 | 240 | 16 | 23 | 3 | 211 | 8 | 395 | 54 |
| 200 MM | 600 | 200 | 340 | 295 | 17 | 23 | 3 | 266 | 12 | 460 | 97.50 |
| 250 MM | 730 | 250 | 400 | 355 | 19 | 28 | 3 | 319 | 12 | 635 | 156 |
| 300 MM | 850 | 300 | 455 | 410 | 20.5 | 28 | 4 | 370 | 12 | 500 | 230 |
