| Part No | Part Name | Material |
|---|---|---|
| 1 | BODY | BRONZE : BS EN 1984 CC 491K |
| 2 | BONNET | BRONZE:BS EN 1984 CC 491 K |
| 3 | BALL | STAINLESS STEEL (SS 304) |
| 4 | SEAT | TEFLON (PTFE) |
| 5 | STEM | STAINLESS STEEL (SS 304) |
| 6 | PACKING RING | TEFLON(PTFE) |
| 7 | HANDLE | TEFLON (PTFE) |
| 8 | BALL | MILD STEEL(MS) |
| 9 | GLAND | BRONZE: BS EN 1984 CC 491 K |
PRESSURE / TEMPERATURE RATING
| Pressure Rating | 25 bar |
| Temperature | -10 to 150 °C |
TEST PRESSURES
| Shell | 37.5 bar |
| Seat | 27.5 bar |
SPECIFICATION
- Ball made of stainless steel,PTFE seats and stem seal.
- Lever made of mild steel with plastic coating
- Lever operated
- End connection: Threaded to BS EN 10226-2(ISO 7-1).
- Testing standard: BS EN 122266-2
DIMENSIONS & WEIGHTS
| Size | A | L | H~ | Weight (kg) |
| 15 MM | 1/2” BSP | 60 | 56 | 0.34 |
| 20 MM | 3/4” BSP | 69 | 64 | 0.48 |
| 25 MM | 1” BSP | 76 | 65 | 0.64 |
| 32 MM | 1-1/4” BSP | 85 | 82 | 1.13 |
| 40 MM | 1-1/2” BSP | 99 | 98 | 1.71 |
| 50 MM | 2 BSP | 125 | 108 | 2.47 |
